1204 SMD LED RED COLOR

Product Item : RD1204BLNB
Category： 1204 SMD LED
Package: SMT package 1204
Wavelength/CT:610~630nm
Color:RED
Intensity:180~280mcd
INQUIRY EMAIL

Descriptions
SMD LED lamps from ArkTech are available in miniature sizes and special configurations for automated PC board assembly and space-sensitive applications. 0603 blue LED is suitable for use in a wide variety of electronic equipment. It is commonly used in indoor and outdoor lighting, such as display, cameras, televisions, etc.

Part No.	Color	Wavelength/CT	Lens type	Intensity	View Angle	VF(V)	IF(mA)
RD1204BLNB	RED Color	610~630NM	Clear	180~280mcd	120°	1.7~2.2V	5mA

Features
3.2 mm x 1.0 mm SMD LED, 1.5 mm thickness
SMT package, colorless diffused resin
Low power consumption
Wide viewing angle.
Package: 3000 pcs / reel
MSL (Moisture Sensitivity Level): 3
Compatible with automatic placement equipment.
Compatible with reflow solder process.
ESD: 8 kV acc. to ANSI/ESDA/JEDEC JS-001 (HBM, Class 3B)
Halogen-free
RoHS compliant

APPLICATIONS
Blue LED is widely used in indoor and outdoor lighting, such as LED light strips, LED bulbs, LED tubes, etc.
ATTENTION
Observe precautions for handling electrostatic discharge sensitive devices. Electrostatic discharge and power surge could damage the LEDs.
It is recommended to use a wrist band or anti-electrostatic glove when handling the LEDs. All devices, equipments and machineries must be electrically grounded.
