5X5mm Rectangular Yellow Color LED

Product Item : LRD55Y03L1
Category： Rectangular shape
Wavelength/CT:590nm
Intensity:160-360mcd
VF(V):2.0~2.5V
IF(mA):20mA
INQUIRY EMAIL

Part No.	Color	Wavelength/CT	Lens type	Intensity	View Angle	VF(V)	IF(mA)
LRD55Y03L1	Yellow	590nm	Yellow	160-360mcd	140°	2.0~2.5V	20mA

FEATURES
Low power consumption
Long life, solid state reliability
Available on tape and reel
RoHS compliant
APPLICATIONS
Status indicator
Illuminator
Signage applications
Decorative and entertainment lighting
Commercial and residential architectural lighting

DESCRIPTION
The Super Bright Yellow device is made with AlGaInP (on GaAs substrate) light emitting diode chip Electrostatic discharge and power surge could damage the LEDs
It is recommended to use a wrist band or anti2electrostatic glove when handling the LEDs
All devices, equipments and machineries must be electrically grounded
All design applications should refer to ArkTech through hole LED application notes.
